| Conductor Material: | Copper Or Tinned Copper | Jacket: | EPR |
|---|---|---|---|
| Insulation: | EPR XLPE Pvc | Braid: | Metal Wire Braid |
1 Brief introduction
The company have been approved by the Classification of Ship of China (CCS) in 2001and have been approved
for rated voltage 1KV and 3KV,6-15KV power cable, rated voltage 150/250V control and instrumentation circuit cable by DEE NORSKE VERITAS
CALSSIFICATION (DNV) in 2004.We have acquired Type Approval Certificate. Our shipboard cable cover 2 series
altogether over 3000tyoe and dimensions that are extensively used in ship’ power, communication, navigation
system and modern warship. The products can also use in oil platform, nuclear power, crane, skyscraper and
other electric project.
2 Standards applied
IEC60228 IEC60092-350 IEC60092-351 IEC60092-353 IEC60092-359
IEC60332-1 IEC60332-3-22 IEC60331 IEC60754-2 IEC60134-2
3 Type and Name
Part one: Shipboard power cable rated voltage 0.6/1kV
|
Cable type |
Description |
|
CJV/DA/SA |
XLPE insulated PVC outer sheath shipboard power cable, type DA,SA |
|
CJY/SC |
XLPE insulated PO outer sheath Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard power cable, type SC |
|
CJVR/DA/SA |
XLPE insulated PVC outer sheath shipboard flexible power cable, type DA,SA |
|
CJYR/SC |
XLPE insulated PO outer sheath Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard flexible power cable, type SC |
|
CJV90DA/SA |
XLPE insulated PVC inner sheath galvanized steel wire braided shipboard power cable, type DA,SA |
|
CJV80/DA/SA |
XLPE insulated PVC inner sheathed tinned copper wire braided shipboard power cable, type DA,SA |
|
CJY90/SC |
XLPE insulated PO inner sheathed galvanized steel wire braided Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard power cable, type SC |
|
CJY80/SC |
XLPE insulated PO inner sheathed tinned copper wire braided Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard power cable, type SC |
|
CJVR90/DA/SA |
XLPE insulated PVC inner sheathed galvanized steel wire braided shipboard flexible power cable, type DA,SA |
|
CJVR80/DA/SA |
XLPE insulated PVC inner sheathed tinned copper wire braided shipboard flexible power cable, type DA,SA |
|
CJYR90/SC |
XLPE insulated PO inner sheathed galvanized steel wire braided Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard flexible power cable, type SC |
|
CJYR80/SC |
XLPE insulated PO inner sheathed tinned copper wire braided Halogen-free, Low-smoke, Low-toxicity flame retardant shipboard flexible power cable, type SC |
