Applied to the ships with the length 12m or above 12m(<50m) as lamp signal liaison when night navigation.
1.It is convenient to install and replace the bulb, and there are automatic aleak holes in the bottom.
2.The shell adopts good quality metal steel , the surface is painted the special mold-powder,has the feature of corrosion resisting and shock resistance.
3.The lampshade adopts PC material, it has the feature of ultraviolet radiation resistance and does not discolor ect.
4.Conform to THE INTERNATION REGULATIONS FOR PREVENTINGS COLLISION AT SEA,1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.
| Name | Type | Visibility | Level arc | Bulb | Bulb | Protection class | Color | Material | Weight |
| starboard light | CXH1-20C | 2n.m | 112.5° | B15d |
24V/30W |
IP55 |
Green | steel | 3.6kg |
| port light | CXH2-20C | 2n.m | 112.5° | B15d |
24V/30W |
IP55 | Red | steel | 3.6kg |
| masthead light | CXH3-20C | 5n.m | 225° | B15d |
24V/30W |
IP55 | Transparent | steel | 3.6kg |
| stern light | CXH4-20C | 2n.m | 135° | B15d |
24V/30W |
IP55 |
Transparent Yellow |
steel | 3.6kg |
| all-round light | CXH6-20C | 2n.m | 360° | B15d |
24V/30W |
IP55 |
Transparent Green Red |
steel | 3.6kg |
