1. Beautiful shape and fine structure,reliable performance.
2. Suitable for fluid drive system.
3. Competitive price.
4. Advanced techniques
| Model | Capacity | Head | Efficiency | NPSH | Speed | Motor power | Overall dimension | Weight |
| (m3/h) | (m) | (%) | r(m) | (r/min) | (kw) | (mm) | (kg) | |
| 32CWL-4 | 4 | 21 | 53 | 4 | 2950 | 1.1Y802-2H(B3) | 731×300×345 | 62 |
| 32CWL-3 | 30 | 42 | 4 | 1.5Y90S-2H(B3) | 762×325×367 | 60 | ||
| 40CWL-5 | 8 | 21 | 59 | 4 | 2950 | 1.1Y80L2-2H(B3) | 726×300×335 | 50 |
| 40CWL-4 | 30 | 50 | 4 | 2.2Y90L-2H(B3) | 796×328×362 | 65 | ||
| 40CWL-3 | 42 | 43 | 4 | 3Y100L-2H(B3) | 846×357×400 | 87 | ||
| 50CWL-6 | 12 | 21 | 59 | 4 | 2950 | 1.5Y90S-2H(B3) | 769×320×337 | 60 |
| 50CWL-4.5 | 30 | 55 | 4 | 3Y100L-2H(B3) | 858×348×363 | 82 | ||
| 50CWL-4 | 42 | 50 | 4 | 4Y112M-2H(B3) | 864×370×400 | 101 | ||
| 50CWL-8 | 21 | 21 | 67 | 4 | 2950 | 2.2Y90L-2H(B3) | 804×335×337 | 65 |
| 50CWL-7 | 30 | 63 | 4 | 4Y112M-2H(B3) | 829×367×372 | 95 | ||
| 50CWL-5 | 42 | 59 | 5 | 5.5Y132S1-2H(B3) | 968×415×396 | 125 | ||
| 50CWL-3.5 | 60 | 55 | 5 | 7.5Y132YS2-2H(B3) | 972×431×450 | 134 | ||
| 65CWL-11 | 35 | 21 | 72 | 4 | 2950 | 4Y112M-2H(B3) | 870×360×357 | 96 |
| 65CWL-8 | 30 | 70 | 4 | 5.5Y132S1-2H(B3) | 958×414×372 | 118 | ||
| 65CWL-6 | 42 | 67 | 5 | 7.5Y132S2-2H(B3) | 948×422×406 | 131 | ||
| 80CWL-14 | 60 | 21 | 75 | 4 | 2950 | 5.5Y132S1-2H(B3) | 981×424×415 | 124 |
| 80CWL-11 | 30 | 75 | 4 | 7.5Y132S2-2H(B3) | 981×431×420 | 132 | ||
| 80CWL-8 | 42 | 73 | 5 | 11Y160M1-2H(B3) | 1175×473×470 | 192 | ||
| 80CWL-6 | 60 | 68 | 5 | 18.5Y160L-2H(B3) | 1202×467×430 | 224 | ||
| 80CWL-5.5 | 75 | 71 | 3.8 | 22Y180M-2H(B3) | 1247×508×545 | 260 | ||
| 100CWL-18 | 100 | 21 | 78 | 4 | 2950 | 11Y160M1-2H(B3) | 1124×470×430 | 154 |
| 100CWL-14 | 30 | 78 | 4 | 15Y160M2-2H(B3) | 1151×480×482 | 213 | ||
| 100CWL-11 | 42 | 77 | 5 | 18.5Y160L-2H(B3) | 1225×490×500 | 242 | ||
| 100CWL-8 | 60 | 75 | 5 | 30Y200L1-2H(B3) | 1372×585×536 | 255 | ||
| 100CWL-6 | 85 | 71 | 5 | 37Y200L2-2H(B3) | 1352×593×563 | 350 | ||
| 150CWL-18 | 160 | 13 | 81 | 5 | 1450 | 11Y160M-4H(B3) | 1218×547×573 | 286 |
| 200CWL-12 | 300 | 30 | 81 | 5 | 37Y225S-4H(B3) | 1508×637×785 | 493 | |
| 200CWL-18 | 400 | 21 | 83 | 5 | 30Y200L-4H(B3) | 1523×631×805 | 472 |
