| Theory: | Centrifugal Pump | Structure: | Multistage Pump |
|---|---|---|---|
| Usage: | Water | Power: | Hydraulic |
| Standard Or Nonstandard: | Standard | Fuel: | Diesel |
| Pressure: | High Pressure | Application: | Sewage |
| Flow: | 3.75-35m3/h | Head: | 19-40m |
Horizontal Single Suction Centrifugal IHF Fluoroplastic Pump Features
The IHF (D) series centrifugal pump is designed according to international standards. The pumping housing is made of metal outing lined with fluoroplastics, and the impeller and pump cover are pressed into form with metal inserts wrapped by fluroplastic alloy, and the shaft seal is realized by mechanically sealing the advanced outer-carrying corrugated pipe. The stationary seal ring is made of 99.9% alumina ceramics. They are corrosion- and wear-resistant and airtight.
Horizontal Single Suction Centrifugal IHF Fluoroplastic Pump Model Significance
IHF 50-32-160 D
IH - International standard chemical industry centrifugal pump
F – The overflow part is fluorine plastic
50 - Inlet Diameter(mm)
32 - Outlet diameter(mm)
160 - Nominal diameter of the impeller(mm)
D – The short bracket structure code
Horizontal Single Suction Centrifugal IHF Fluoroplastic Pump Specifications
| Model | Flow | Lift | Efficiency | NPSh | Inlet×Outlet | Speed | Motor Power | Weight |
| m3/h | m | % | m | mm | r/min | kw | kg | |
| IHF50-32-160(D) | 7 | 33 | 35 | 3.2 | 50×32 | 2900 | 4 | 95 |
| *12.5 | 32 | 47 | ||||||
| 15 | 30 | 47 | ||||||
| IHF50-32-200(D) | 7 | 51 | 28 | 3.2 | 50×32 | 2900 | 7.5 | 135 |
| *12.5 | 50 | 40 | ||||||
| 15 | 49 | 48 | ||||||
| IHF65-50-125(D) | 15 | 22 | 46 | 3.5 | 65×50 | 2900 | 3 | 90 |
| *25 | 20 | 61 | ||||||
| 35 | 16 | 67 | ||||||
| IHF65-50-160(D) | 15 | 33 | 45 | 3.5 | 65×50 | 2900 | 5.5 | 125 |
| *25 | 32 | 56 | ||||||
| 35 | 30 | 65 | ||||||
| IHF80-65-125(D) | 35 | 22 | 52 | 4 | 80×65 | 2900 | 5.5 | 125 |
