1.FEATURE:
CYZ series centrifugal diesel fuel pump belongs to self-priming centrifugal oil pump,and the feature is simple construction,easy operation,convenient repairing,high displacement,high efficiency,wide application scope etc..
2.APPLICATION:
Type CYZ centrifugal diesel fuel pumps are used to deliver the petrol,kerosene,diesel oil,etc.,and the temperature of medium is -20°c~+80°c.
CYZ series centrifugal diesel fuel pump is a knd of load and unload oil pump in boat.
CYZ series diesel fuel pump can be used to convey oil in the land oil depot and oil truck.
In addition,the CYZ diesel pump also can carry the sea water and fresh water,etc..
3.FUNCTION DATA:
| Model | Capacity (m3/h) | Head | Speed | (NPSH)r | Ability of self-priming | Axle-power | Inlet and outlet diameters |
| (m) | (r/min) | (m) | (min/sm) | (KW) | (mm) | ||
| 40CYZ-20 | 6.3 | 20 | 2900 | 3.5 | 2 | 0.88 | 40×32 |
| 40CYZ-40 | 10 | 40 | 2900 | 3.5 | 1.5 | 2.8 | 50×40 |
| 50CYZ-12 | 15 | 12 | 2900 | 3.5 | 2.5 | 1.1 | 50 |
| 50CYZ-20 | 18 | 20 | 2900 | 3.5 | 2 | 1.8 | 50 |
| 50CYZ-35 | 14 | 35 | 2900 | 3.5 | 1.5 | 2.7 | 50 |
| 50CYZ-50 | 12.5 | 50 | 2900 | 3.5 | 1.5 | 4.3 | 50 |
| 50CYZ-60 | 15 | 60 | 2900 | 3.5 | 1.5 | 6.3 | 50 |
| 50CYZ-75 | 20 | 75 | 2900 | 3.5 | 1.5 | 9.9 | 50 |
| 65CYZ-15 | 30 | 15 | 2900 | 4 | 2 | 1.92 | 65 |
| 65CYZ-30 | 25 | 30 | 2900 | 4 | 2 | 3.2 | 65 |
| 80CYZ-13 | 35 | 13 | 2900 | 4 | 3.5 | 1.9 | 80 |
| 80CYZ-25 | 50 | 25 | 2900 | 4 | 1.5 | 5.2 | 80 |
| 80CYZ-32 | 50 | 32 | 2900 | 4 | 1.5 | 6.8 | 80 |
| 80CYZ-55 | 60 | 55 | 2900 | 4 | 1.5 | 15.0 | 80 |
| 80CYZ-70 | 60 | 70 | 2900 | 4 | 1.2 | 20.1 | 80 |
| 100CYZ-40 | 100 | 40 | 2900 | 4 | 2 | 18.3 | 100 |
| 100CYZ-40A | 100 | 40 | 1470 | 4 | 1.5 | 18.5 | 100 |
| 100CYZ-65 | 100 | 65 | 2900 | 4 | 2 | 27.7 | 100 |
| 100CYZ-75 | 70 | 75 | 2900 | 4 | 2 | 24.2 | 100 |
| 150CYZ-55 | 160 | 55 | 2900 | 5 | 2 | 38.1 | 150 |
| 150CYZ-65 | 170 | 65 | 1470 | 5 | 1.3 | 51.0 | 150 |
| 200CYZ-63 | 280 | 63 | 1480 | 5 | 1.5 | 75.1 | 200 |
