1)Marine weathertight single-steel door
2)The products won LR,BV,ABS, GL,NK,CCS,DNV certificate
3)Used for the doorway of superstructure above freeboard deck or deck house meet ISO6042-1980
size is optional and customized
| Code of standard |
Size of doorway H*W*R |
Size of door (H1*W1*R1) |
Hole size of casting wall (H2*W2*R2) |
Thickness of door sheet |
Weight (kg) |
| 1050 | 1000*500*100 | 1049*549*124.5 | 1100*600*150 | 6 | 92.3 |
| 1050*551*125.5 | 8 | 103.8 | |||
| 1260 | 1200*600*100 | 1249*649*124.5 | 1300*700*150 | 6 | 113.4 |
| 1251*651*125.5 | 8 | 129.0 | |||
| 1460 | 1400*600*100 | 1449*649*124.5 | 1500*700*150 | 6 | 128.6 |
| 1451*651*125.5 | 8 | 146.7 | |||
| 1475 | 1400*750*100 | 1449*799*124.5 | 1500*850*150 | 6 | 144.4 |
| 1451*951*125.5 | 8 | 165.9 | |||
| 1490 | 1400*900*100 | 1449*949*124.5 | 1500*1000*150 | 6 | 160.1 |
| 1451*951*125.5 | 8 | 185.2 | |||
| 1660 | 1600*600*100 | 1649*649*124.5 | 1700*700*150 | 6 | 136.9 |
| 1651*801*125.5 | 8 | 154.8 | |||
| 1675 | 1600*750*100 | 1649*799*124.5 | 1700*850*150 | 6 | 161.4 |
| 1651*951*125.5 | 8 | 185.7 | |||
| 1690 | 1600*900*100 | 1649*949*124.5 | 1700*1000*150 | 6 | 178.0 |
| 1651*951*125.5 | 8 | 206.4 |
