Product Details:
Payment & Shipping Terms:
|
Material: | Steel Or Carbon Steel |
---|
Designed for towing with steel and nylon/polypropylenerope
1.Material of hook:EH36
2.Certificate:CCS,ABS,BV,DNV,GL.LR,KR
Long economic life of over 25 years.
Warranty : We undertake to remedy any defective components, caused by poor design, material or workmanship for the goods supplied.
Our liability is limited to replacing the defective parts, which appear within a period of 12 months from date of invoice, provided that our storage, installation, operating and maintenance manual is properly followed.
Minimum maintenance
The disc rotating system avoids high release impact on the hook and foundation.
The towing hooks are free-swivelling so sliding or gliding plates are not required.
SWL:70KN-1000KN (70kN, 150kN, 250kN, 450kN, 650kN, 1000kN)
Testload :140KN-1500KN (140kN, 300kN, 500kN, 650kN, 1300kN, 1500kN)
Releaseload:70KN-1000KN (70kN, 150kN, 250kN, 450kN, 650kN, 1000kN)
Weight: 79KGS-1282KGS ( 79kgs, 174kgs, 414kgs, 534kgs, 918kgs, 1282kgs)
All our towing hook can be supplied with various options such as
1. Small fairlead for guiding manual release wire to bridge/wheelhouse.
2. Mounting foundation for mounting the towing hook onto the ship’s deck. The foundation can be
welded or bolted onto the ship’s deck, and/or horizontal brackets.
3. Electric-Pneumatic Remote Control system.
4. Electric-Hydraulic Remote Control system.
5. Spring shock-absorber construction.
6. Radial arm construction and fixed radial construction.
7.Load Monitoring System for continuous measurement of towing loads.
8. Anti-slip-rope device(“keeper”)
