Product Details:
Payment & Shipping Terms:
|
Working Pressure: | 0.12Mpa | Size: | Per To Your Requests |
---|---|---|---|
Application: | Boat/ship Safty | R (KN): | 2019KN |
GEA (KJ): | 2019KN |
1.The advantages of pneumatic rubber fender
1.1 Choose reinforce synthetic-tire-cord layers
1.2 No mold vulcanization and attach surrounding molding process
1.3 High energy absorption and low reaction force
1.4 Good adaptability to tilt in contact
1.5 Floating on the surface of the water, ship swaying can apply
2.Structure characteristics of the pneumatic rubber fender
Pneumatic Rubber Fenders are made of an outer rubber, reinforcement synthetic-tyre-cord layer, and inner rubber, vulcanized firmly.
A]. the outer rubbers are used to protect the cord layers and inner rubber from abrasion and other external forces. This rubber compound have sufficient tensile and tear resistance strength to withstand anticipated weather conditions and severe usage.
B]. the reinforcement synthetic-tyre-cord layer strong enough to maintain the internal air pressure of the fender.
C]. the inner rubber layer seals the pressurized air inside the fender.
D]. fenders of diameter 2500mm and larger equipped with safety valve for releasing excess internal pressure when the fenders are over-compressed accidentally.
Fender assembly for the end of metal, by inside and outside the two flanges with bolts, nut clamping, center is a valve, its structure is similar to automobile tire valve.
Size |
Initial Internal Pressure 0.05MPa |
Weight ±10% |
Initial Internal Pressure 0.08MPa |
Weight ±10% |
||
D*L(mm) |
R(KN) |
GEA(KJ) |
Kg |
R(KN) |
GEA(KJ) |
Kg |
500*1000 |
64 |
6 |
25 |
83 |
8 |
25 |
600*1000 |
74 |
8 |
32 |
96 |
11 |
32 |
700*1500 |
137 |
17 |
50 |
178 |
24 |
50 |
1000*1500 |
182 |
32 |
80 |
235 |
44 |
80 |
1000*2000 |
257 |
45 |
100 |
335 |
63 |
125 |
1200*2000 |
297 |
63 |
120 |
386 |
86 |
165 |
1350*2500 |
427 |
102 |
165 |
554 |
140 |
226 |
1500*3000 |
597 |
153 |
315 |
751 |
211 |
370 |
1700*3000 |
639 |
191 |
405 |
830 |
263 |
436 |
2000*3500 |
875 |
308 |
590 |
1138 |
424 |
632 |
2500*4000 |
1381 |
663 |
1050 |
1815 |
925 |
1110 |
2500*5500 |
2019 |
943 |
1333 |
2653 |
1317 |
1410 |
3000*5000 |
2104 |
1210 |
1880 |
2709 |
1571 |
2155 |
3000*6000 |
2583 |
1485 |
2160 |
3292 |
1888 |
2470 |
3300*4500 |
1884 |
1175 |
2020 |
2476 |
1640 |
2300 |
3300*6500 |
3015 |
1814 |
2700 |
3961 |
2532 |
3080 |
