Marine Mooring Cast steel Double Bollards

China Marine Mooring Cast steel Double Bollards supplier
Marine Mooring Cast steel Double Bollards supplier Marine Mooring Cast steel Double Bollards supplier Marine Mooring Cast steel Double Bollards supplier Marine Mooring Cast steel Double Bollards supplier

Large Image :  Marine Mooring Cast steel Double Bollards

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: LR,CCS,ABS,BV,DNV,RINA,KR
Model Number: CCM5

Payment & Shipping Terms:

Minimum Order Quantity: 2
Price: Negotiable
Packaging Details: standard packaging
Delivery Time: 10 days
Payment Terms: T/T or L/C
Supply Ability: 1000 Pc per month
Contact Now
Detailed Product Description

Material: Casting Steel

Information:35T-440kg/PC,50T-665kg/PC,70T-1100kg/PC,100T-1670kg/PC

Six anchor bolts per pcs.



Capacity Weight Bollard Anchor Bolt Anchor PL
TONS KG D A B B1 H H1 H2 H3 T d L Q'ty W t
35 440 300 600 720 810 690 65 65 290 25 42 850 6 168 35
50 665 350 700 840 945 780 70 70 330 29 48 1000 6 192 40
70 1100 400 800 1000 1130 900 90 90 370 33 56 1150 6 225 45
100 1670 450 900 1200 1365 990 95 95 410 39 64 1300 6 256 55







3500x6500mm Marine Sling Type Floating Pneumatic Rubber with lightweight.
