Product Details:
Payment & Shipping Terms:
|
Diameter Range:: | 28mm--150mm | Load Capacity:: | 4400-4800teu |
---|
. Material: Nylon
2. Dia: 28mm--150mm
3. Certificates: CCS, ABS, LR, NK, BV, DNV-GL, RS, KR
4. Advantages: High strength, light weight, easy operation, soft and wearing resisting.
5. Use: Widely used in shipbuilding, ocean transportation, ship towing, sea aid, heavy-duty hoisting, national defense warship and vessel etc.
Product Parameters
Specification | Polyamide Multifilament | Polyamide Line | Polypropylene Filament | Polyester | Polyester/ Polypropylene |
||||||
Dia. | Cir. | Linear density | MBL | Linear density | MBL | Linear density | MBL | Linear density | MBL | Linear density | MBL |
mm | inch | Ktex | daN | Ktex | daN | Ktex | daN | Ktex | daN | Ktex | daN |
28 | 3-1/2 | 465 | 18500 | 452 | 13800 | 365 | 12100 | 605 | 14000 | 500 | 12700 |
32 | 4 | 605 | 23500 | 585 | 17600 | 470 | 15300 | 795 | 18000 | 660 | 16000 |
36 | 4-1/2 | 770 | 29200 | 745 | 21900 | 600 | 19100 | 1000 | 22400 | 820 | 20000 |
40 | 5 | 950 | 35200 | 920 | 26400 | 740 | 22700 | 1245 | 27000 | 1000 | 23800 |
44 | 5-1/2 | 1150 | 41400 | 1120 | 31000 | 900 | 27200 | 1500 | 32000 | 1200 | 28500 |
48 | 6 | 1360 | 50000 | 1320 | 37500 | 1080 | 32500 | 1820 | 38000 | 1450 | 34200 |
52 | 6-1/2 | 1590 | 58500 | 1550 | 44000 | 1270 | 38000 | 2130 | 45500 | 1680 | 40000 |
56 | 7 | 1850 | 65600 | 1800 | 49000 | 1480 | 43000 | 2470 | 51000 | 1960 | 45400 |
60 | 7-1/2 | 2120 | 75600 | 2060 | 56500 | 1700 | 49400 | 2830 | 57000 | 2270 | 51000 |
64 | 8 | 2420 | 85800 | 2350 | 63500 | 1920 | 55500 | 3230 | 66500 | 2550 | 58000 |
72 | 9 | 3060 | 110000 | 2970 | 79000 | 2430 | 69500 | 4080 | 81500 | 3270 | 73000 |
80 | 10 | 3780 | 128000 | 3670 | 93800 | 3010 | 83000 | 4950 | 98000 | 4000 | 87200 |
88 | 11 | 4580 | 151000 | 4440 | 113000 | 3650 | 97800 | 5980 | 120000 | 4820 | 108000 |
96 | 12 | 5450 | 178000 | 5290 | 134000 | 4250 | 116000 | 7130 | 144000 | 5910 | 138000 |
104 | 13 | 6390 | 207000 | 6200 | 155000 | 5000 | 135000 | 8360 | 165000 | 6920 | 156000 |
112 | 14 | 7410 | 239000 | 7180 | 180000 | 5820 | 157000 | 9690 | 191000 | 7950 | 182000 |
120 | 15 | 8510 | 274000 | 8260 | 206000 | 6630 | 180000 | 11100 | 218000 | 9100 | 206000 |
128 | 16 | 9705 | 350000 | 9430 | 265000 | 7600 | 230000 | 12700 | 280000 | 1045 |
