VESSEL OPEN TYPE LIFEBOAT FOR LIFE-SAVING APPLIANCE
Overview
*The Totally enclosed Lifeboat/Rescue boat is manufactured with compliance with the(amendments to the SOLAS, 1974), MSC218.(82),MSC226.(82),MSC272.(85)and MSC274.(85).
*The hull/canopy of lifeboat is made of the fire reinforced plastic(F.R.P.—fire retardant ). The space between the inside and outside hull/canopy is filled with polyurethane foam which will supply sufficient buoyancy for the boat.
*The boat will be afloat with the help of the foam even the part of boat underneath the water damaged.
*The fully loaded boat will be selfrighted when the boat turn over to any angle. This type of boat is used for the life-saving and rescue on the sea.
Features
* Amendments to the international convention for the safety of safety of life at sea,1974.
* International life-saving appliance(LSA),code MSC.218(82),MSC.272(85).
*MSC.81(70),MSC.226(82), MSC.274(85)The resolution for maritime safety committee.
*Nation calibrate for F.R.P. Material.
*Approval:ABS,EC,DNV,BV &CCSETC...for Totally enclosed Lifeboat/Rescue boat
Types of lifeboat/ Rescue Boat and application
*Totally enclosed Lifeboat/Rescue boat or Gravitational collapse lifeboat,20-120 persons
*Free Fall Life Boat 12-36 persons
*Rescue Boat 6 persons
*Fast Rescue Boat 6-12 persons
*Inflated Fender/Rigid Fast Rescue Boat
*Each vessel Match lifeboat standard:
Totally enclosed Lifeboat/Rescue boat(Gravity type): one ship, two enclosed lifeboat with davit
Free Fall Lifeboat:One ship,one free fall lifeboat
*Application:CARGO VERSION,TANKER VERSION,MARINE OFFSHORE,PLATFORM ETC...
Products Details OF OPEN TYPE TOP LIFEBOAT
Model |
35K |
45K |
52K |
60K |
70K |
75K |
80K |
|
Length |
m |
3.55 |
4.55 |
5.28 |
6.08 |
7.12 |
7.53 |
8.02 |
Breadth |
m |
1.60 |
1.86 |
2.10 |
2.10 |
2.35 |
2.55 |
2.65 |
Depth |
m |
0.80 |
0.85 |
0.95 |
0.95 |
1.03 |
1.05 |
1.10 |
Hook distance |
m |
2.83 |
3.80 |
4.50 |
5.30 |
6.00 |
6.50 |
7.00 |
Craft weight |
kg |
695 |
770 |
1364(674) |
1320(715) |
1730(1329) |
1887(1475) |
2249(1645) |
Persons |
P |
7 |
10 |
16(16) |
22(25) |
33(36) |
43(46) |
52(55) |
Full Load |
kg |
1220 |
1520 |
2564(1874) |
2970(2590) |
4205(4029) |
5112(4925) |
6149(5770) |
Speed |
|
≥10km/h |
≥6 knots |
|||||
Engine |
|
ZS1100 |
ZX2105C-1 |
|||||
Power |
HP |
15 |
24 |
|||||
Rotate speed |
rpm |
2200 |
1500 |
|||||
Remark |
|
Only used in inland river |
The particulars in bracket is without engine |
