Type: heavy type (E) or light type (F)
Series: regular series, fire-resistant series,heated series
Installation: Bolt fixed rectangular window or welded rectangular window
Frame material: brass, aluminum, steel
Glass: toughened glass
Cutout in bulkhead: 429x574mm to 2504x1804mm
Nominal size: 355x500mm to 2400x1700mm
Glass thickness: E: 10mm to 19mm F: 8mm to 15mm
Main Size List (mm):
|
Series |
Type |
Code |
Nominal Size |
Opening Size |
Frame |
Opening |
||
|
wxh |
W1xh1 |
r |
W2xh2 |
W3xh3 |
||||
|
N, P, H |
E,F |
1 |
300x425 |
352x477 |
76 |
348x473 |
430x555 |
ILB,ILW,IRB,IRW,ITB,ITW,OLB, OLW,ORB,ORW,OTB,OTW,NOB,NOW |
|
2 |
355x500 |
407x552 |
76 |
403x548 |
485x630 |
|||
|
3 |
400x560 |
452x612 |
76 |
448x608 |
530x690 |
|||
|
4 |
450x630 |
502x682 |
126 |
498x678 |
580x760 |
|||
|
5 |
500x710 |
552x762 |
126 |
548x758 |
630x840 |
|||
|
6 |
560x800 |
612x852 |
126 |
608x848 |
690x930 |
|||
|
7 |
900x630 |
952x682 |
126 |
948x678 |
1030x760 |
|||
|
8 |
1000x710 |
1052x762 |
126 |
1048x758 |
1130x840 |
|||
|
9 |
1100x800 |
1152x852 |
126 |
1148x848 |
1230x930 |
|||
