Product Details:
Payment & Shipping Terms:
|
Application: | Anchoring, Towing, Mooring | Wire Rope Capacity: | 1-5000m |
---|---|---|---|
Speed: | 1-15m/min |
1. We are the Group company which has 6 subsidiary companies with 200 millions USD yearly output value.
2. The few factory which can produce the construction winch, marine winch, mine winch with electric type, hydraulic type , diesel engine type.
3. With 3 senior engineers are the drafters of China Winch National Standard .We are the council member of Chinese winch association.
4. The leader of 6S management in winch and crane industry.
5. Our engineers are available to overseas anytime anywhere.
6.All kinds of winch can be customized according to your demands.
Model | Rated load | Rated speed | Rope capacity | Rope diameter | Motor power | Overall Dimensions |
KN | m/min | m | mm | KW | mm | |
YT1-16 | 160 | 7.5 | 500 | 28 | 45 | 3200x4050x2200 |
YT1-20 | 200 | 7.5 | 500 | 30 | 55 | 3200x4050x2200 |
YT1-25 | 250 | 7.5 | 550 | 32 | 75 | 3600x4350x2580 |
YT1-32 | 320 | 7.5 | 600 | 36 | 90 | 3600x4500x2600 |
YT1-40 | 400 | 5 | 750 | 40 | 90 | 3700x4800x2860 |
YT1-50 | 500 | 5 | 750 | 52 | 110 | 3900x4900x3000 |
YT1-63 | 630 | 5 | 850 | 54 | 110 | 4000x5100x3100 |
YT1-80 | 800 | 5 | 1000 | 58 | 132 | 4250x5300x3300 |
YT1-100 | 1000 | 5 | 1000 | 64 | 180 | 4550x5500x3450 |
YT1-125 | 1250 | 5 | 1200 | 70 | 220 | 4850x5800x3700 |
YT1-130 | 1300 | 5 | 1200 | 72 | 220 | 5000x6800x3800 |
YT1-160 | 1600 | 4 | 1500 | 82 | 220 | 5200x7000x3860 |
YT1-200 | 2000 | 4 | 1500 | 90 | 250 | 5350x7200x4000 |
YT1-250 | 2500 | 4 | 1500 | 102 | 300 | 5500x7450x4200 |
YT1-300 | 3000 | 4 | 1500 | 110 | 360 | 5800x7600x4200 |
