Product Details:
Payment & Shipping Terms:
|
Material: | PE | Specification: | Dn20mm-Dn1200mm |
---|---|---|---|
Length: | 6m, 12m Or As Required | Thickness: | 2.3mm-81.8mm |
Standard: | ISO4427/4437, DIN8074/8075 | Pipe Color: | Black With Blue Or Yellow Stripe |
PE Pipe Features:
1. Long working life. Minimum 50 years life under nomal conditions.
2. Hygiene. PE pipe are nontoxic, without the composition of heavy metal additives. No scale, not breeding germ, no second pollution to the potable water.
3. High resistance to attack from various types of chemicals. No electrochemical corrosion.
4. Smooth internal surface. Extremely low friction coefficient. Improved capability for media to pass through. Excellent abrasive resistance.
5. Good flexibility, high resistance to impact. Resistance to earthquake and twisting.
6. Light weight, easy to transport, convenient installation.
7. Unique electro fusion welding and butt welding make the joints stronger than the material, to guarantee a safe and reliable joint.
8. Simple welding technique, convenient installation. Total cost is low for the installation.
9. Polyethylene water pipes are produced in black, black with blue stripes and blue etc
PE Pipe Connection:
Socket fusion, butt fusion joint, electro fusion joint, flanged joint
PE Pipe Application:
Water supply, industrial liquids transportation, sewage treatment. Mariculture, and agricultural irrigation, etc.
PE100 pipe for water supply specifications:
Nominal external diameter | Nominal wall thickness | ||||
Standard size ratio | |||||
SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 | |
Nominal pressure | |||||
0.60 | 0.80 | 1.0 | 1.25 | 1.60 | |
32 | 3.0 | ||||
40 | 3.7 | ||||
52 | 4.6 | ||||
63 | 4.7 | 5.8 | |||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 8.2 | |
110 | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 |
125 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 |
140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 |
355 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 24.1 | 30.0 | 37.4 | 46.3 | 57.2 |
710 | 27.2 | 33.9 | 42.1 | 52.2 | 63.6 |
800 | 30.6 | 38.1 | 47.7 | 58.8 | 72.7 |
900 | 34.4 | 42.9 | 53.3 | 66.2 | 81.8 |
1000 | 38.2 | 47.7 | 59.3 | 73.5 | |
1200 | 46.2 | 57.1 | 70.6 |
