| Working Pressure: | 0.12Mpa | Size: | Per To Your Requests |
|---|---|---|---|
| Application: | Boat/ship Safty |
Low reaction and high absorption energy fender with low surface preeure.
Easy of installation and repair.
Macimum permissible service life.
* SIZE
300Ø x 500L ~ 4500Ø x 9000L
having smaller counteracting force,more contact area with ships,smaller pressure on ships per unit,its capablity not reducing when being leaned and compressed,and simple installation.Suitable for ship berthing of all directions,currently it has been widely used in many tyres of ship berthing,and it is also suitable for the berthing in ports
|
Specification D×Lm |
Initial pneumatic pressure 0.05Mpa |
Initial pneumatic pressure 0.08Mpa |
||||
|
Sphere Weight(KG) |
R(KN) |
GEA(KJ) |
Sphere Weight(KG) |
R(KN) |
GEA(KJ) |
|
|
0.5×1.0 |
25 |
64 |
6 |
25 |
85 |
8 |
|
0.6×1.0 |
32 |
74 |
8 |
32 |
98 |
11 |
|
0.7×1.5 |
50 |
137 |
17 |
50 |
180 |
24 |
|
1.0×1.5 |
80 |
182 |
32 |
80 |
239 |
45 |
|
1.0×2.0 |
100 |
257 |
45 |
125 |
338 |
63 |
|
1.2×2.0 |
120 |
297 |
63 |
165 |
390 |
88 |
|
1.35×2.5 |
165 |
427 |
102 |
226 |
561 |
142 |
|
1.5×3.0 |
315 |
579 |
153 |
370 |
761 |
214 |
|
1.7×3.0 |
405 |
639 |
191 |
436 |
840 |
287 |
|
2.0×3.5 |
590 |
875 |
308 |
632 |
1150 |
430 |
|
2.5×4.0 |
1050 |
1381 |
663 |
1110 |
1815 |
925 |
|
2.5×5.5 |
1333 |
2019 |
943 |
1410 |
2653 |
1317 |
|
3.0×5.0 |
1880 |
2000 |
1050 |
2155 |
2709 |
1571 |
|
3.0×6.0 |
2160 |
2488 |
1312 |
2470 |
3292 |
1888 |
|
3.3×4.5 |
2020 |
1884 |
1175 |
2300 |
2476 |
1640 |
|
3.3×6.0 |
2300 |
2783 |
1675 |
2600 |
3652 |
2338 |
|
3.3×6.5 |
2700 |
3015 |
1814 |
3080 |
3961 |
2532 |
|
3.3×10.6 |
4403 |
5257 |
3067 |
5020 |
6907 |
4281 |
|
4.5×9.0 |
6554 |
5747 |
4752 |
7470 |
7551 |
6633 |
|
4.5×12.0 |
8739 |
7984 |
6473 |
9960 |
10490 |
9037 |
|
Note: The weight is the fender weight (excluding protective sleeve), with weight error of±10% and counterforce error pf±10% |
||||||
