Marine Boat Rubber Fender Pneumatic Rubber Fenders

China Marine Boat Rubber Fender Pneumatic Rubber Fenders supplier
Marine Boat Rubber Fender Pneumatic Rubber Fenders supplier Marine Boat Rubber Fender Pneumatic Rubber Fenders supplier Marine Boat Rubber Fender Pneumatic Rubber Fenders supplier Marine Boat Rubber Fender Pneumatic Rubber Fenders supplier

Large Image :  Marine Boat Rubber Fender Pneumatic Rubber Fenders

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: LR,CCS,ABS,BV,DNV,RINA etc
Model Number: CCM2

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: standard packaging
Delivery Time: 10 days
Payment Terms: T/T or L/C
Supply Ability: 1000 Pc per month
diameter: 500-3300mm
Length: up to 12m
material: natural rubber
Detailed Product Description

Pneumatic rubber fender(or inflatable rubber fender) is the advanced anti-collision device for marine application in the world today,it has a long and successful history of protecting vessels in mooring operations. They are ideal for permanent and semi-permanent port applications and for offshore ship-to-ship transfers.

Pneumatic rubber fenders uses compressed air as medium to absorb the impact energy when ship-to-ship contact (STS) and ship-to-berthing (STB).
Comparing with traditional bumper style rubber fender, it has the following advantages:
1. more energy absorption
2. less reverse impact on ships
3. less weight, easy installation
4. softer and economical



Specifications
D*L(m)






Initial pneumatic pressure 0.05MPa

Initial pneumatic pressure 0.05MPa


Applicable ships tonnage
(T)


Remark




Sphere
Weight
(kg)



R(KN)






GEA(KG)






Sphere
Weight
(kg)



R(KN)




GEA(KG)




0.5*1.0

25

64

6

25

83

8

50

Fishing ship

0.6*1.0

32

74

8

32

96

11

50

Fishing ship

0.7*1.0

50

137

17

50

178

24

100

Fishing ship

1.0*1.5

80

182

32

80

235

44

100

Fishing ship

1.0*2.0

100

257

45

125

335

63

200

Fishing ship, Tugboat

1.2*2.0

120

297

63

165

386

86

300-500

Fishing ship, Tugboat

1.35*2.5

165

427

102

226

554

140

300-500

Fishing ship, Tugboat

1.5*3.0

315

597

153

370

751

211

1000

Tugboat,Transportation ships

1.7*3.0

405

639

191

436

830

263

1000

Deep sea trawling ships,Transportation ships

2.0*3.5

590

875

308

632

1138

424

3000

Deep sea trawling ships,Transportation ships

2.5*4.0

1050

1381

663

1110

1815

925

10000

Transportation ships

2.5*5.5

1333

2019

943

1410

2653

1317

10000

Transportation ships

3.0*5.0

1880

2104

1210

2155

2709

1571

10000above

Transportation ships

3.0*6.0

2160

2583

1485

2470

3292

1888

10000above

Transportation ships

3.3*4.5

2020

1884

1175

2300

2476

1640

10000above

Transportation ships

3.3*6.0


2300

2783

1675

2600

3652

2338

10000above

Transportation ships

3.3*6.5

2700

3015

1814

3080

3961

2532

10000above

Transportation ships







3500x6500mm Marine Sling Type Floating Pneumatic Rubber with lightweight.
