Product Details:
Payment & Shipping Terms:
|
| Color: | Optional |
|---|
Technical Standards
1. Operation encironment: coastal harbour,inland river,rocks,reef and bank etc.
2. Working temperature: -40~60°C.
3 Wind resistance:12 levels.
4. Ware resistance: grade 9.
5. Service life:10 years.
|
Model and Specification |
HBF3.0 |
HBF2.4 |
HBF1.8 |
HBF1.5 |
HBF1.2 |
|
Diameter(mm) |
3000 |
2400 |
1800 |
1500 |
1200 |
|
Height of buoy(mm) |
7350 |
6540 |
4450 |
3140 |
2620 |
|
Depth (mm) |
3400 |
3050 |
2050 |
1350 |
1200 |
|
height of focal plane(m) |
4250 |
3800 |
2710 |
2080 |
1710 |
|
Weight of buoy(kg) |
2450 |
1650 |
850 |
380 |
270 |
|
Weight of configuration (kg) |
500 |
300 |
300 |
200 |
100 |
|
Modulator |
HD155-S2 or HD160-B1 LED |
HD-90-S1 |
|||
|
Energy |
Major |
Sea water power source |
Silicon solar battery |
||
|
Minor |
Zinc air battery or silicon solar battery |
Zinc air battery |
|||
|
Optical range of visibility(mil) |
>6 |
>6 |
>6 |
>4 |
>4 |
|
Depth of throw(m) |
13-40 |
13-40 |
5-20 |
5-15 |
5-10 |
