Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers

China Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier
Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers supplier

Large Image :  Marine Cast Steel Roller Pawl Type Anchor Chain Stoppers

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: LR,CCS,ABS,BV,DNV
Model Number: CCM9

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: standard packaging
Delivery Time: 10 days
Payment Terms: T/T or L/C
Supply Ability: 1000 Pc per month
Contact Now
Detailed Product Description

Roller pawl type chain stopper:
Marine Cast Steel Roller Pawl Type anchor Chain Stopper JIS F2032:
Chain Stopper is a device between anchor windlass and hawsepipe, it can fix the anchor chain prevent it roll out. .When the vessel mooring ,chain stopper transport the pull strength of anchor and chain to vessel, can reduce the working load protect the anchor windlass. When sailing it stand the anchor weight and inertial force.
Customized service is available, Advanced equipment ,Strong consciousness in controlling quality
Process:casting, forging, welding,casting
Provide CCS,ABS,NR,DNV,etc certificate
Material:Cast iron, cast steel.


JIS F2032 Cast Steel Roller Pawl Type Chain Stopper
Dimensions(mm)
Nominal Chain Dia.(mm)hh1h2LL1L4BbDWeight
(kg)
70-731254228606606402419801155841096
76-7813345091870068025410461236241316
81-8414348398376072027911101346721608
87-90153515105581077029511901437201938
92-95162545111586081031712501517602286
97-102175584119592086033713201618162787
105-107185617126598190036413901708643274
111-1141956511335102694037614601809123874
117-1222086951427110099540815501919764600
127-132225750154211901060441166020710565750

Also we can supply other type chain stopper as follows:
JIS F2002-1976 cast iron Bar Type Chain Stopper
JIS F2015-1987 Cast Steel Bar Type Chain Stopper
JIS F2023-1976 Cast Steel Bar Type Chain Stopper
JIS F2031 Pawl Type Chain Stopper
JIS F2032 Roller Pawl Type Chain Stopper
JIS F2033 Roller Bar Type Chain Stopper type B
OCIMF Type single point mooring Chain Stopper
CB286-84 cast steel lever chain stopper
GB/T 3844-2000 Marine roller lever chain stopper
GB/T 178-96 spiral type chain stopper/ screw type chain stopper
Smith towing bracket for chain stopper
OCIMF Type Towing Bracket
Non-standard chain stopper,we can customized it according to your drawing
