BV Certified SHF1 Sheathed Marine telecommunication cable

China BV Certified SHF1 Sheathed Marine telecommunication cable supplier
BV Certified SHF1 Sheathed Marine telecommunication cable supplier BV Certified SHF1 Sheathed Marine telecommunication cable supplier BV Certified SHF1 Sheathed Marine telecommunication cable supplier BV Certified SHF1 Sheathed Marine telecommunication cable supplier BV Certified SHF1 Sheathed Marine telecommunication cable supplier BV Certified SHF1 Sheathed Marine telecommunication cable supplier

Large Image :  BV Certified SHF1 Sheathed Marine telecommunication cable

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: ABS,GL,LR,BV,DNV Certified
Model Number: CYDL-5

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: standard packaging
Delivery Time: 7 days
Payment Terms: T/T
Supply Ability: 10000 per month
Contact Now
Detailed Product Description

Mairne Telecommunication cable 250V

Product Description:

1. EPR insulated shipboard telecommunication cable


2. EPR insulated shipboard fire-resisting telecommunication cable


3. PVC insulated shipboard telecommunication cable


4. PVC insulated fire-resisting shipboard telecommunication cable


5. XlPE insulated shipboard telecommunication cable


6. XLPE insulated fire-resisting shipboard telecommunication cable

STANDARDS:

IEC 60288 IEC60092-350 IEC60092-353 IEC60092-359
IEC60092 351 IEC60332-1 IEC60332-3Cat.A
IEC61034-2 IEC 60754-2 3A

Cable Construction:
Conductor: tinned copper
Insulation: EPR/PVC/XLPE
Filler
Tape
Inner sheath: PCP/CSP/PVC/PO (SHF1, SHF2)
Armored: tinned copper wire braid
(Galvanized steel wire braid)
Outer sheath: PolyvinylChloride/Cross-linked Polyolefin/ Thermoplastic Polyolefin

Application:
The cable is intended for communication, computer and information proceeding unit of shipboard and naval ship, and it is also available to metallurgical industry chemical works, power planted and mines etc.

Certificates:
CCS, LR, ABS, DNV, BV, GL, NK, RINA; 85 degree Celsius
The radius of bend for the installation of cables:
Cable structure features Over diameter of cable(D) Minimum internal bending radius
Metal braided armored            Any value                     6D
Non-armored                           D≤25                        4D








3500x6500mm Marine Sling Type Floating Pneumatic Rubber with lightweight.
