Marine Ram type steering gear

China Marine Ram type steering gear supplier
Marine Ram type steering gear supplier Marine Ram type steering gear supplier Marine Ram type steering gear supplier Marine Ram type steering gear supplier

Large Image :  Marine Ram type steering gear

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: ABS EC GL CCS BV
Model Number: CCM9

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 30 days
Payment Terms: T/T L/C
Supply Ability: 100 PER month
Contact Now
Detailed Product Description

The series of ram type steering gear mainly consists of a set of propelling machinery which is composed of 2 piston type cylinders dedicated for steering gear,2 oil pump generator systems,1 reservation oil tank,additionally a set of emergency pump,accumulator or a set of direct current motor pump unit are added for the inland river rapids navigating area in order to satisfy the emergency requirements of rules. The rudder gear can be controlled by hand,valve,pump,from which,the valve control,the pump control can be matched to use with any type automatic steering control system and the follow-up steering apparatus.

(1)Suitable for:
Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any other vessels that need more steering torque.
(2)Main Tech:
Max working torque:              15 KN.M — 250 KN.M
Max. mech. rudder angle:       ± 45 degree
Time of rudder movement:     ≤28 S
Rudder stock Diameter:          300mm — 900 mm
Working pressure:                  13 Mpa — 20 Mpa
Design pressure:                    16 Mpa — 24 Mpa
(3)Scope of delivery:
Marine steering gear with hydraulic cylinders
Electro-Hydraulic power station with oil pumps
Oil tanks
Start motors
On requests, the full range of  parts will be delivered.
(4)Certificates:
 The provided products can be delivered with certifications of ABS,GL, BV,LR and CSS, and other certifications can be served according to the customers.







Working Torque
(KN.M)

Max mech
Rudder
angle

Time of
rudder movement
(s)

Working pressure(Mpa)

Designed pressure
(Mpa)

Motor power
(kW)

Dimensions
(unit: mm)

A

B

C





MDEE060-FM06

630

±45°

≤28

15

18.8

37

3914

2300

1033

MDEE060-FM07

680

±45°

≤28

16.2

20.3

37

3914

2300

1033

MDEE060-FM08

700

±45°

≤28

16.7

20.9

37

3914

2300

1033

MDEE060-FM09

750

±45°

≤28

17.9

22.4

37

3914

2300

1033

MDEE060-FM10

780

±45°

≤28

18.6

23.3

37

3914

2300

1033

MDEE060-FM11

800

±45°

≤28

13.5

16.9

45

3914

2300

1110

MDEE060-FM12

880

±45°

≤28

14.9

18.6

45

3914

2300

1110

MDEE060-FM13

900

±45°

≤28

15

18.8

45

3914

2300

1110

MDEE060-FM14

930

±45°

≤28

15.7

19.7

45

3914

2300

1110

MDEE060-FM15

1000

±45°

≤28

16

20

45

3914

2300

1110

MDEE060-FM16

1200

±45°

≤28

14.8

18.5

45

4300

2800

1220

MDEE060-FM17

1500

±45°

≤28

17.6

22

55

4300

2800

1220

MDEE060-FM18

2000

±45°

≤28

15

18.8

75

4800

3100

1340

MDEE060-FM19

2500

±45°

≤28

18

22.5

90

4800

3100

1340








3500x6500mm Marine Sling Type Floating Pneumatic Rubber with lightweight.
