Marine High Performance Pneumatic Rubber Fender

China Marine High Performance Pneumatic Rubber Fender supplier

Large Image :  Marine High Performance Pneumatic Rubber Fender

Product Details:

Place of Origin: Jiangsu
Brand Name: CCME
Certification: LR,CCS,ABS,BV,DNV
Model Number: CCM3

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: standard packaging
Delivery Time: 10 days
Payment Terms: T/T or L/C or Westunion
Supply Ability: 1000 Pc per month
Contact Now
Detailed Product Description
Working Pressure: 0.12Mpa Size: Per To Your Requests
Application: Boat/ship Safty R (KN): 2019KN
Material: Natural Rubber+durable Dipped Tyre

Constructure



1)Outer rubber layer

Rubber layer that covers the outside of the fender to protect the cord layers and the inner liner rubber from abrasion and other external forces.

2)Inner rubber layer

liner of a rubber membrane that seals the pressurized air inside the fender.(In general,we will make some inner rubber container in advance and inflate them.few days later,we will test the pressure again.The one which it's pressure did not change is good one.We will put it into store and when clients order we can use it directly.This can ensure every fender we send to client is airtight one)

3. Flange opening

which is mounted on the fender to which an air valve can be adapted.(our flange are all Embedded welding, very stable)

4. Initial internal pressure

Air pressure at which an uncompressed fender operates.

yokohama pneumatic fender

2.There are two types Pneumatic rubber marine fender  :

1)Sling-type fender:fender which is designed to be used without a protection net.



Size

Initial Internal

Pressure  0.05MPa

Weight

±10%

Initial Internal

Pressure  0.08MPa

Weight

±10%

D*L(mm)

R(KN)

GEA(KJ)

Kg

R(KN)

GEA(KJ)

Kg

500*1000

64

6

25

83

8

25

600*1000

74

8

32

96

11

32

700*1500

137

17

50

178

24

50

1000*1500

182

32

80

235

44

80

1000*2000

257

45

100

335

63

125

1200*2000

297

63

120

386

86

165

1350*2500

427

102

165

554

140

226

1500*3000

597

153

315

751

211

370

1700*3000

639

191

405

830

263

436

2000*3500

875

308

590

1138

424

632

2500*4000

1381

663

1050

1815

925

1110

2500*5500

2019

943

1333

2653

1317

1410

3000*5000

2104

1210

1880

2709

1571

2155

3000*6000

2583

1485

2160

3292

1888

2470

3300*4500

1884

1175

2020

2476

1640

2300

3300*6500

3015

1814

2700

3961

2532

3080











3500x6500mm Marine Sling Type Floating Pneumatic Rubber with lightweight.
